MPN
PIC18F43K20-E/PT
Manufacturer
Description
Microcontroller, 8-Bit, FLASH, PIC18 CPU, 64MHz, CMOS, PQFP44
MPN
PIC18F43K20-E/PT
Total Available Quantity
-
Main Attributes
Core Architecture
PIC
Max Frequency
64MHz
RAM Size
512B
Specifications
Mount
Surface Mount
Case/Package
TQFP
Number of Pins
44
Data Bus Width
8b
Frequency
64MHz
Memory Size
8kB
Memory Type
FLASH
Min Supply Voltage
1.8V
Max Supply Voltage
3.6V
Min Operating Temperature
-40°C
Max Operating Temperature
125°C
RoHS
Compliant
Interface
I2C, SPI, UART, USART
Lead Free
Lead Free
Max Power Dissipation
1W
Number of Programmable I/O
36
Number of Timers/Counters
4
Peripherals
HLVD, POR, PWM, WDT
Radiation Hardening
No
Watchdog Timer
Yes
About This Product
The Microchip PIC18F44K20 is a versatile 8-bit microcontroller designed for a wide range of embedded applications. Featuring a powerful PIC18 CPU that operates at a maximum frequency of 64MHz, this microcontroller is equipped with 8kB of FLASH memory and a robust set of peripherals, making it ideal for both simple and complex tasks. Housed in a compact TQFP package with 44 pins, it supports multiple interfaces including I2C, SPI, UART, and USART, ensuring seamless integration into various systems. With a wide operating temperature range from -40°C to 125°C, this microcontroller is suitable for demanding environments, providing reliability and performance.
