MPN
900-83668-0030-000
Total Available Quantity
20
Lead time to Ship
1-2 weeks
Ships from
USA
Country of Origin
-
Date Code
-
Main Attributes
Series
NVIDIA Jetson Xavier NX Series
Class
Consumer
Specifications
Processor
Carmel ARMv8.2
Ethernet
Gigabit Ethernet
3.5mm Audio Jack
No
Bluetooth
No
CSI Camera Port
14-lane MIPI CSI-2 display interface
Display Port (Nvidia Specific)
1.4
DL Accelerator (Nvidia Specific)
2x NVDLA
DSI Display Port (Raspberry Pi Specific)
No
GPIO Access
No
HDMI Port
1 x HDMI interface
HTS
8471.50.0150
Input Power
5V
M.2 Key E (Nvidia Specific)
No
M.2 Key M (Nvidia Specific)
No
Max Operating Temperature
50°C
Min Operating Temperature
-30°C
Multimedia
Encode: 2x 4K60 | 4x 4K30 | 10x 1080p60 | 22x 1080p30 (H.265) 2x 4K60 | 4x 4K30 | 10x 1080p60 | 20x 1080p30 (H.264) Decode: 2x 8K30 | 6x 4K60 | 12x 4K30 | 22x 1080p60 | 44x 1080p30 (H.265) 2x 4K60 | 6x 4K30 | 10x 1080p60 | 22x 1080p30 (H.264)
Package Quantity
50
Packaging
Bulk
PCIe (Nvidia Specific)
x1 PCIe Gen3 x4 PCIe Gen4
Processor Speed
1.9GHz
RAM
16GB LPDDR4X SDRAM
SD Card Support
No
Storage eMMC
16GB
Sub-Architecture
Volta GPU with 48 Tensor Cores
USB Ports
1 x USB 3.1 3 x USB 2.0
Vision Accelerator (Nvidia Specific)
2x PVA
Wireless LAN
No
MPN
900-83668-0030-000
Total Available Quantity
20
Lead time to Ship
1-2 weeks
Ships from
USA
Country of Origin
-
Date Code
-
